Personal RF monitor - 100 kHz to 60 GHz: WaveMon RF-60 | Wavecontrol

The WaveMon RF-60 is a personal RF monitor designed for occupational and public RF safety from 100 kHz to 60 GHz. It continuously evaluates exposure levels and provides immediate warnings when configurable exposure thresholds are reached.

The instrument integrates isotropic electric and magnetic field sensors with RMS response, a built-in datalogger, audible and vibratory alarms, and optional GPS and altimeter for geolocated exposure studies. It is designed for use by workers operating near RF sources in telecommunications, industry, railway, medical, defence, aeronautical and laboratory environments.

The WaveMon RF-60 is available in several versions shaped to specific RF safety standards, including ICNIRP, FCC, EU Directive 2013/35/EU, Safety Code 6 and NATO standards.

Benefits

• Personal RF safety monitoring: designed to be worn on a harness, belt or arm holder during field operations.
• Wide RF coverage: electric field monitoring from 100 kHz to 60 GHz and magnetic field monitoring from 3 MHz to 1 GHz, depending on the selected version.
• Immediate overexposure warning: high-intensity audible and vibratory warnings based on instant and average exposure values.
• Standard-based response: versions shaped to occupational and public RF safety standards.
• Exposure percentage display: front LEDs indicate exposure as a percentage of the selected standard.
• Integrated datalogger: stores more than 1,000,000 events for exposure studies.
• Optional geolocation: GPS and altimeter options allow exposure data to be linked to position and altitude.
• Long autonomy: rechargeable and replaceable batteries with more than one month of autonomy in typical working conditions.
• 5G-ready: designed for RF safety monitoring in environments including 5G deployments.

Key features

• Sensor type: isotropic RMS diode technology.
• Electric field frequency range: 100 kHz to 60 GHz, depending on version.
• Magnetic field frequency range: 3 MHz to 1 GHz, depending on version.
• Response: shaped to specific standards according to the selected model.
• Dynamic range: up to 1000%.
• Linearity: 0.5 dB for E-field from 2% to 200%, and 0.5 dB for H-field from 5% to 200%.
• Interface: one ON/OFF button with status and low battery LED.
• Indicators: 6 LEDs, audio warning and vibration warning.
• Alarm thresholds: two alarm thresholds adjustable by the user.
• Connectivity: waterproof USB for data download and battery charging.
• Falling detection: integrated fall detection function.
• Logging interval: adjustable from 1 second to 60 minutes.
• Averaging interval: adjustable from 1 second to 60 minutes.
• Battery type: 2 x AA NiMH rechargeable batteries via USB.
• Protection rating: IP54.
• LF immunity: greater than 30 kV/m at 50/60 Hz.
• Temperature range: -20 °C to +50 °C; charging from 0 °C to +40 °C.
• Dimensions: 174 x 42.5 x 33 mm.
• Weight: 190 g.

Typical applications

• Worker RF safety: personal monitoring for personnel working near RF transmitters or energized telecom infrastructure.
• Telecommunications: RF exposure monitoring during installation, maintenance and audit of communication sites.
• Industry: protection of workers exposed to RF sources in industrial facilities.
• Railway: personal RF monitoring in railway and transport environments.
• Medical environments: RF exposure monitoring for personnel working near relevant electromagnetic sources.
• Defence and aeronautical: personal safety monitoring for RF exposure in technical and operational environments.
• Laboratories: exposure monitoring during RF research, testing and validation activities.

Why choose WaveMon RF-60

The WaveMon RF-60 is designed for organizations that need a wearable, standards-based solution for personal RF exposure monitoring. Its combination of isotropic RMS sensors, shaped response, direct exposure percentage indication and high-intensity alarms helps field personnel identify potentially unsafe RF conditions in real time.

The integrated datalogger, optional GPS and altimeter, and adjustable logging and averaging intervals make it suitable not only for immediate protection but also for structured exposure studies and compliance documentation. With versions aligned to major RF safety frameworks, the WaveMon RF-60 can be selected according to the standard used by the organization or project.
