Multi-Channel Soil Gas Flux Measurement System: SF-3500 | LICA UNITED TECHNOLOGY LTD
The SF-3500 Multi-Channel Soil Gas Flux Measurement System is an advanced solution developed by LICA United Technology to address the spatial and temporal variability of soil gas flux. It enables multi-point, long-term, and automatic monitoring of gas fluxes such as CO₂, CH₄, N₂O, and NH₃ across diverse ecosystems.
PRICE ON REQUEST
The SF-3500 Multi-Channel Soil Gas Flux Measurement System is an advanced solution developed by LICA United Technology to address the spatial and temporal variability of soil gas flux. It enables multi-point, long-term, and automatic monitoring of gas fluxes such as CO₂, CH₄, N₂O, and NH₃ across diverse ecosystems. The system can connect to various greenhouse gas analyzers and stable isotope analyzers to perform synchronized multi-parameter flux measurements with high precision. Its robust design, integrated control, and wireless data transmission make it ideal for field research and environmental monitoring in demanding conditions.
Advantages:
- Multi-gas compatibility – supports simultaneous measurement of CO₂, CH₄, N₂O, NH₃, and isotope gases such as ¹³CO₂, ¹²C¹⁸O¹⁶O, and ¹⁵N¹⁴NO.
- Multi-analyzer connection – connects to multiple gas analyzers for synchronous multi-parameter flux analysis, reducing system error.
- Automatic data processing – real-time calculation of gas flux, no need for post-processing.
- Touchscreen and mobile control – LCD display and Android App for full control without a computer.
- Wireless data transmission – remote control and monitoring for easy field operation.
- Durable and field-ready – designed for long-term, stable operation in outdoor conditions.
Main Specifications:
| SF-3500 Multiplexer | |
|---|---|
| Number of chamber interfaces | 9 or 18 |
| Storage medium | SD card |
| Communication interface | Bluetooth, Wi-Fi |
| Operating temperature | −20 °C to +45 °C |
| Operating humidity | 0 – 95 % RH (non-condensing) |
| SC-22 Automated Soil Flux Chamber | |
|---|---|
| Measurement area | 298.5 cm² |
| Chamber volume | 3341 cm³ |
| Cable length | 1.5 m |
| Pump flow rate | 3.5 L / min |
| Operating temperature | −20 °C – +45 °C |
| Air pressure range | 15 – 115 kPa (± 1.5 %) |
| Temperature range | −25 °C – +85 °C (± 0.5 °C) |
| Dimensions | 245 mm (L) × 245 mm (W) × 590 mm (H) |
Typical Applications:
- Soil greenhouse gas monitoring – long-term multi-gas flux observation in agricultural, forest, and wetland ecosystems.
- Climate and carbon research – quantification of CO₂ and CH₄ emissions for carbon cycle studies.
- Agricultural science – assessment of N₂O emissions and fertilizer management impact.
- Isotopic studies – high-precision analysis of stable isotope gas fluxes.
- Environmental monitoring networks – integration into multi-station systems for continuous data collection.
Why Choose the SF-3500:
The SF-3500 combines precision, automation, and versatility in one compact platform. It enables researchers to monitor multiple soil flux points simultaneously and continuously, while reducing operational complexity and measurement error. Built for Canadian field conditions, it ensures reliable data collection in variable climates — from wetlands to northern forest ecosystems. Supported by ES Canada’s environmental instrumentation expertise, the SF-3500 offers local service, technical support, and lifetime assistance for research institutions and environmental organizations.
