Vape Detector: GS601 | Milesight

The GS601 is a professional-grade vape detection sensor designed for educational institutions, public buildings, commercial facilities, and high-compliance environments requiring accurate monitoring of vaping, smoke, environmental pollutants, and potential fire risks. Leveraging advanced multi-sensor fusion and LoRaWAN® connectivity, the GS601 provides real-time alerts, robust anti-tamper protection, and precise aerosol detection, making it an ideal solution for bathrooms, locker rooms, and other low-visibility indoor spaces. Its compact ceiling-mount design ensures discreet installation while delivering continuous, high-resolution environmental intelligence.

Advantages :

• Multi-sensor integration
• Real-time status alerts
• Resilient against environmental interference
• Adjustable buzzer hibernation duration
• Instant flame alarming
• Anti-tamper & theft protection
• Affordable and cost-effective

Main Features :

Key Features

• Cigarette Detection: Including cigarette and other burnt nicotine
• Weed Detection: Including vape and smoked ones
• Environmental Factors: Including temperature, humidity, PM1.0/2.5/10, and TVOC
• High Accuracy: Resistant to water vapor and other gas interferences
• Buzzer Hibernate: Prevents false alarms during deployment
• Flame Alarming: Monitors temperatures (20°C – 60°C) to detect potential fire hazards
• Status Alerts: Real-time alerts with buzzer and LED indicators for rapid intervention
• Anti-Tamper & Theft Protection: Built-in vibration sensor for system security

Wireless Transmission

• Technology: LoRaWAN®
• Antenna: Internal Antenna
• Frequency: RU864 / IN865 / EU868 / US915 / AU915 / KR920 / AS923-1/2/3/4
• Tx Power: 16 dBm (868 MHz) / 22 dBm (915 MHz)
• Sensitivity: –137 dBm @ 300 bps
• Mode: OTAA / ABP Class C

Sensors

Temperature:

• Operating Principle: Digital CMOSens® technology (MEMS)
• Range: –20°C ~ 60°C
• Accuracy: ± 0.2°C
• Resolution: 0.1°C

Humidity:

• Operating Principle: Digital CMOSens® technology (MEMS)
• Range: 0% ~ 100% RH
• Accuracy: ± 2% RH
• Resolution: 0.5% RH

Vape Index:

• Operating Principle: Laser Scattering
• Range: 0 ~ 100
• Accuracy: ± 10
• Resolution: 1

TVOC:

• Operating Principle: MOX (MEMS)
• Range: 0 ~ 2000 μg/m³
• Accuracy: 20 μg/m³ ±15% of readings (1 ~ 500 μg/m³)
• Resolution: 1 μg/m³

PM1.0 & PM2.5 & PM10:

• Operating Principle: Laser Scattering
• Range: 0 ~ 1000 μg/m³
• PM1.0 & PM2.5 Accuracy: 0–100 μg/m³: ±10 μg/m³; 100–1000 μg/m³: ±10% of measured value
• PM10 Accuracy: 0–100 μg/m³: ±25 μg/m³; 100–1000 μg/m³: ±25% of measured value
• Resolution: 1 μg/m³

Others

• Button: 1 × Reset Button (External)
• LED & Buzzer: 1 × Status/Alarm Indicator + 1 × Buzzer (70 dB @ 1 m)
• USB: 1 × USB Type-C Port for Power Supply

Software

• Configuration: Mobile App via NFC or Downlink
• Advanced Features: Threshold Alarm, Tamper Alarm, Calibration, FUOTA

Physical Characteristics

• Power Supply: 5V/1A via Type-C Port or optional PoE Splitter
• Operating Temperature: –5°C ~ 45°C
• Relative Humidity: 0 ~ 95% (non-condensing)
• Ingress Protection: IP30
• Color: White
• Weight: 178.6 g
• Dimensions: Ø 128 × 40 mm (Ø 5.04 × 1.57 in)
• Installation: Ceiling Mount

Approvals

• Regulatory: CE, FCC
• Environmental: RoHS
